Shaanxi Qi Delong 18 square stirring truck chassis parameters Vehicle Name: Shaanxi Qi Delong 18 square stirring truck Engine Weichai 375 hp Volume (ml) 11596 Overall dimensions(mm) 11800x2500x4000 Mixing volume 16m3 Total weight (kg) 31000(Kg) Service weight (kg) 15000(Kg) Rated ma...
Vehicle Name: | Shaanxi Qi Delong 18 square stirring truck | Engine | Weichai 375 hp |
Volume (ml) | 11596 | Overall dimensions(mm) | 11800x2500x4000 |
Mixing volume | 16m3 | Total weight (kg) | 31000(Kg) |
Service weight (kg) | 15000(Kg) | Rated mass (kg) | 14490.14425(Kg) |
Number of spring pieces | 12/12/10.4/4.5 | Axle load | 6500/6500/18000 |
Wheel base | 1800+3050+1350,1410(mm) | Maximum speed | 83(km/h) |
Speed changing box | Fast 12 speed | Front and rear axles | 9 ton front axle and 16 ton rear axle |
Number of tires | 10+1 | Wheel specification | 12.00R20 Original steel wire tyre |
Front gauge | 2005、2005 | Track rear | 1865/1865 |
